IP65 P8mm Transparent LED Curtain Display 1R1G1B LED Glass Screen
Features:
1. Conduction-cooled, with mute power supplies;
2. Quick lock system to improve the speed of install by 80%;
3.Die-casting aluminum cabinet- high precision, Much light ;
4.Supports fixed and hoisting structure installation, with fast
installation and quick dis-assembly, widely used in stage rental
etc..
| Specifications - Technical Data | ||||||||
| Model | HRTOR-P8 | |||||||
| LED Module/ Cabinet | Pixel pitch | P8 | ||||||
| Cabinet size | 1000*500 | |||||||
| Encapsulation | SMD | |||||||
| Pixel density | 7200dots/㎡ | |||||||
| Pixel configuration | ||||||||
| Module/Pixel resolution | 120*30 | |||||||
| Average power | 167W/㎡ | |||||||
| LED Screen | Refresh frequency | ≥1920HZ/S | ||||||
| Grey scale | 14bit | |||||||
| Transparent ratio | 43% | |||||||
| Brightness (cd/m²) | 6500mcd/㎡ | |||||||
| Life-span | 80,000Hours | |||||||
| Viewing angle | 120°/120° | |||||||
| Protection grade | IP65 | |||||||
| Maintenance | Front/back | |||||||
| Input voltage | AV240 or 110±10% | |||||||
|
|
